| WATER COOLED DIESEL GENERATOR SET | |||||||||
| Model | KW at 50HZ(1500rpm) | Diesel Engine | Displacement(L) | Fuel consumption (g/kw.h) | No.of cylinder/ configuration | Dimension (L*W*H/mm) | N.W(KGS) | ||
| prime | standby | Cummins | Open Type | Soundproof type | Open Type | ||||
| GF3-C16KW | 16 | 18 | 4B3.9-G2 | 3.9 | 210 | 4/L | 1700*700*7080 | 2200*850*1450 | 750 |
| GF3-C20KW | 20 | 22 | 4B3.9-G2 | 3.9 | 210 | 4/L | 1700*700*7081 | 2200*850*1451 | 750 |
| GF3-C25KW | 25 | 28 | 4BT3.9-G2 | 3.9 | 210 | 4/L | 1700*700*7082 | 2200*850*1452 | 820 |
| GF3-C30KW | 30 | 32 | 4BT3.9-G2 | 3.9 | 210 | 4/L | 1700*700*7083 | 2200*850*1453 | 820 |
| GF3-C40KW | 40 | 45 | 4BTA3.9-G2 | 3.9 | 210 | 4/L | 1700*700*7084 | 2500*900*1600 | 900 |
| GF3-C45KW | 45 | 50 | 4BTA3.9-G2 | 5.9 | 210 | 4/L | 1760*750*1250 | 2500*900*1601 | 900 |
| GF3-C70KW | 70 | 77 | 6BT5.9-G | 5.9 | 210 | 6/L | 2100*785*1330 | 3000*1050*1650 | 1050 |
| GF3-C78KW | 78 | 86 | 6BT5.9-G | 5.9 | 210 | 6/L | 2100*785*1331 | 3000*1050*1651 | 1050 |
| GF3-C90KW | 90 | 99 | 6BT5.9-G | 5.9 | 210 | 6/L | 2100*785*1332 | 3000*1050*1652 | 1150 |
| GF3-C100KW | 100 | 110 | 6BTA5.9-G2 | 5.9 | 210 | 6/L | 2100*785*1333 | 3100*1100*1700 | 1200 |
| GF3-C110KW | 110 | 121 | 6BTAA5.9-G2 | 5.9 | 210 | 6/L | 2100*785*1334 | 3300*1150*1700 | 1300 |
| GF3-C130KW | 130 | 145 | 6CTA8.3-G2 | 8.3 | 210 | 6/L | 2420*800*1660 | 3350*1300*1750 | 1700 |
| GF3-C140KW | 140 | 150 | 6CTA8.3-G2 | 8.3 | 210 | 6/L | 2420*800*1661 | 3350*1300*1751 | 1750 |
| GF3-C160KW | 160 | 180 | 6CTAA8.3-G2 | 8.3 | 210 | 6/L | 2420*950*1660 | 3700*1300*1850 | 1800 |
| GF3-C200KW | 200 | 220 | 6LTAA8.9-G2 | 8.9 | 210 | 6/L | 2420*950*1661 | 3700*1300*1851 | 2080 |
| GF3-C240KW | 240 | 264 | NTA855-G1 | 14 | 210 | 6/L | 3000*1100*1750 | 4200*1500*2100 | 2750 |
| GF3-C275KW | 275 | 303 | NTA855-G1B | 14 | 210 | 6/L | 3020*1100*1900 | 4200*1500*2101 | 2950 |
| GF3-C315KW | 315 | 347 | NTA855-G3 | 14 | 210 | 6/L | 3020*1100*1901 | 4200*1500*2102 | 3250 |
| GF3-C360KW | 360 | 400 | KTA19-G3 | 18.9 | 208 | 6/L | 3400*1360*2031 | 4500*1600*2201 | 4300 |
| GF3-C400KW | 400 | 440 | KTA19-G4 | 18.9 | 208 | 6/L | 3400*1360*2032 | 4500*1600*2202 | 4350 |
| GF3-C450KW | 450 | 500 | KTAA19-G5 | 18.9 | 208 | 6/L | 3650*1800*2100 | 4800*1800*2400 | 4600 |
| GF3-C500KW | 500 | 550 | KTAA19-G6A | 18.9 | 208 | 6/L | 3650*1800*2101 | 4800*1800*2401 | 4600 |
| GF3-C600KW | 600 | 660 | KTA38-G2 | 38 | 208 | 12/L | 4800*2060*2452 | 40HQcontainer | 7750 |
| GF3-C720KW | 720 | 800 | KTA38-G2A | 38 | 208 | 12/L | 4800*2060*2453 | 40HQcontainer | 7850 |
| GF3-C800KW | 800 | 880 | KTA38-G4 | 38 | 208 | 12/L | 5200*2100*2600 | 40HQcontainer | 8200 |
| GF3-C900KW | 900 | 1000 | KTA38-G9 | 38 | 208 | 12/L | 5200*2100*2601 | 40HQcontainer | 9450 |
| GF3-C1000KW | 1000 | 1100 | KTA50-G9 | 50.3 | 208 | 16/L | 5200*2100*2602 | 40HQcontainer | 9850 |
