| Diesel Generator with Yangdong Engine | ||||||||||||||
| Genset Model | GF3-Y8KW | GF3-Y10KW | GF3-Y12KW | GF3-Y15KW | GF3-Y20KW | GF3-Y25KW | ||||||||
| Frequency(Hz) | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | ||
| Power | KW | 8 | 8 | 10 | 12 | 12 | 15 | 15 | 20 | 20 | 25 | 25 | 30 | |
| KVA | 10 | 10 | 12.5 | 15 | 15 | 18 | 17.48 | 25 | 25 | 30 | 31.25 | 37 | ||
| Disele Engine | Diesel engine Model | 380 | 480 | 485 | 490 | 4100 | 4102 | |||||||
| Engine Speification | Water-cooled,4-storke,in-line,direct injection,1500rpm | |||||||||||||
| Bore×Storke(mm) | 80×85 | 80×90 | 85×90 | 90×100 | 100×115 | 102×118 | ||||||||
| Rated output(kW) | 10 | 12 | 14 | 17 | 17 | 20 | 21 | 25 | 27 | 33 | 33 | 39 | ||
| Fuel consumption(g/kw.hr) | ≤247 | ≤250.6 | ≤248.9 | ≤247.5 | ≤237 | ≤238 | ||||||||
| Lube consumption(g/kw.hr) | ≤2.72 | |||||||||||||
| Aspiration | Natural | |||||||||||||
| Compression ratio | 18:01 | |||||||||||||
| Starting | Electric(12V) | |||||||||||||
| Alternator | Model | 164B | 164C | 164D | 184E | 184F | 184G | |||||||
| Rated power(kW) | 8.8 | 10.8 | 12.8 | 18 | 22 | 25 | ||||||||
| Voltage | 230/400 | 230/400 | 230/400 | 230/400 | 230/400 | 230/400 | ||||||||
| Dimensions LWH(mm) | 1600×800×950 | 1830×800×950 | 2000×900×1040 | |||||||||||
| Net Weight(kg) | 650 | 700 | 750 | 800 | 900 | 950 | ||||||||
