| DIESEL GENERATOR SPECIFICATION |
| Model | DY9800LN |
| Rate power(Kw) | 7 |
| Max Power (kw) | 7.5 |
| Frequency(Hz) | 50/60 |
| Voltage(AC)(V) | 220/230/240,110/220V,120/240V,220/380V,230/400V,240/415V |
| Current(A) | 34A( Single Phase), 10A/14A(Three Phase) |
| Engine speed(rpm) | 3000/3600 |
| Starting system | Electric Start |
| Net weight(kg) | 210 |
| Engine model | DY198F(E) |
| Type | Single cylinder,vertical,,air cooled diesel engine |
| Cooling type | Force air-cooled |
| Engine power(kw) | 9.9/10.5 |
| Bore × Stroke(mm) | 98*84 |
| Displacement(cc) | 633 |
| Fuel Tank Capacity(L) | 15 |
| Packing dimensions (L×W×H)mm | 1100*650*850 |
